Installation of Wazuh in Ubuntu 24.04.2

Introduction

Wazuh is an open-source solution that enables organizations and individuals to enhance their capabilities in threat prevention, detection, and response. It also integrates features of Extended Detection and Response (XDR) and Security Information and Event Management (SIEM), providing a comprehensive platform for real-time monitoring, threat analysis, and security event correlation.

You can deploy Wazuh in single mode (All-in-One) or multi-node (Distributed mode).

• Single-mode deployment will combine all Wazuh components (Wazuh indexer, manager, and Dashboard) into a single instance.
• Multi-node deployment will distribute the Wazuh components across the different instances for high availability (HA) and scalability.

Also, Wazuh has two installation methods

• Assisted installation: The script will automate and install all components and configurations.
• Step-by-step installation: This method provides instructions for each command while installing all components and configuration.

This post will go with a single-mode deployment and an assisted installation method.

Prerequisites

• Ubuntu server 24.04.2
• Internet connection to the Ubuntu server

Initial procedures to do before installation

You must confirm the server's DNS name if it suits you.

Run the below command to check your hostname

#hostname

To change the hostname, run the following command

#hostnamectl set-hostname

To make it permanent, changing /etc/hosts file is recommended to point to the correct hostname.

Run the below command to edit the file.

#nano /etc/hosts

Press Ctrl + X, Y, and Enter to save the file.

Now, move to update and upgrade the packages available on the server

Run the below command

#apt-get update && apt-get upgrade

Wazuh installation

Login to a server and become the sudo user (root).

Initial configuration

In this step, we will download the installation assistance and configuration file

Run the below commands

#curl -sO https://packages.wazuh.com/4.12/wazuh-install.sh

#curl -sO https://packages.wazuh.com/4.12/config.yml

Now, we need to change the config.yml file to reflect the details we have in our server.

Run the below command to edit the configuration file

#nano config.yml

From the above file (config.yml), change the name and IP address to what you want, and put your server's IP address.

For example, I want to use an indexer name called “echo_indexer”, for Wazuh manager I will use “echo_wazuh”, and for the dashboard I will use “echo_dash”, and my IP address is 192.168.68.128.

Wazuh components installation

The next step is to run the Wazuh installation assistant script with the --generate-config-files option to generate Wazuh certificate, cluster key, and passwords, which are important files during the Wazuh installation. You can find those files in wazuh-install-files.tar

Run the below command to generate those files

#bash wazuh-install.sh --generate-config-files

Now, we are ready to proceed with the installation of Wazuh components (indexer, manager, filebeat, and dashboard)

Review the options we have by running the command below.

#bash wazuh-install.sh

You will find more options here. But for our case, we will go with the -a option, which will install and configure all Wazuh components.

Go and run the command below.

#bash wazuh-install.sh -a

It will start installing Wazuh indexer, Wazuh manager, and the dashboard. Keep your eye on the screen until you get the last output of the command.

Copy those credentials somewhere else because we will use them to login.

Access your Wazuh dashboard.

Go into your favourite browser and try putting this URL https://

For my case, I will put https://192.168.68.128.

It will prompt you to a security concern about the certificate (Your connection is not private)

Click Advanced and click the link below it to proceed.
Now, use the credentials you have for the admin to log in to the Wazuh dashboard.

Congratulations, you have installed Wazuh on your server.

Now, we should plan the following things

• Data onboarding
• Data retention
• Rule Tuning and Alert Noise Reduction
• Alerting and Notification Setup
• Dashboards and Visualization
• User and Access Management
• Backup and Recovery Strategy
